MINDA SOLUTIONS

06 The individual stacks or bundles are assembled to the desired layer pat- tern in the palletizer line. Thanks to the modular design, customer require- ments can be implemented individually and accommodated in production in a space-saving manner. This means that the layers can be deposited alternately by the turning device and, if required, doubled or tripled. Depending on your requirements, the following features can be integrated optionally: • Using a stack doubler/tripler • Feeding a second intermediate sheet • Integrating a turning device In addition, an automatic empty pallet infeed is possible. Of course, we exclusively use our Spherical Cross and Spherical Table components to create the layer. As a result, we do not use lifting movements and offer you a rather open and accessible system. PALLETIZER STRATOR MACHINE PERIPHERY FOR THE CORRUGATED BOARD INDUSTRY Technical data Max. layer pattern L x W: 1,600 x 1,600 mm Min. sheet size L x W: 700 x 600 mm Min. sheet size 2,000 – 2,400 mm Speed 180 layers / hour with single layer Speed with stack doubler 360 layers / hour with double layer Centering unit, intermediate sheet dispenser and protection sheet dispenser are included in the scope of delivery. The control side as well as other adjustments are optionally available.
